Pacraft TX-100SP-1 – Center Spout Inserting Machine

PACRAFT TX-100SP-1
Center Spout Inserting Machine

• Automatically loads bulk spouts and bulk pouches to produce high-quality pre-spouted pouches.

• Completed pouches are transferred to rails for shipping to the end user or transferred directly to the filling operation when used as part of an interlocked pouch production and filling system.

• Highly precise spout positioning system.

• 4-stage heat/heat/heat/cool sealing method for uniform, high-quality spouted pouch production.

• Optional vacuum decay leak detection and machine vision spout alignment verification systems.

• Provides significant cost reduction when used as part of an interlocked pouch production and filling system.

• Eliminates the need to ship and store pre-spouted pouches, as well as shipping cartons and rails.

Specifications

Model	TX-100SP-1
Machine Dimension	W2796 x L2662 x H1900 mm.
Capacity	max.100 ppm
Pouch Type	Stand up pouch, Gusset pouch, Flat pouch
Pouch Size	W: 70-100 mm , L:120-250 mm
Electric Power	13 KVA
Air Cinsumption	0.5 MPa, 800 NL/min (ANR)
Cooling Water	0.2 MPa, 5 L/m
