PACRAFT TT-15C-14 Spout Insert Fill Capper

PACRAFT TT-15C-14 is an automatic spout inserting, filling, and capping machine designed for center-spout pouches. It enables precise liquid filling and secure capping, ideal for beverages, purees, baby food, nutritional liquids, and liquid detergents.

Categories : PACKAGING MACHINE , SPOUT POUCH PACKAGING MACHINES

Brands :PACRAFT

Product description

PACRAFT TT-15C-14
Spout Insert Fill Capper

Combination spout inserter, filler / capper automatically seals spouts into pre-made pouches, then fills and caps the pouch.
Spouted pouch hiling & capping machine for beverages, purees, baby food, nutritional & dietary liquid detergents & others.
Two stage vacuum / fll nozzles insure pouch is completely flled with very low residual air. Optional N2 fush system.
Torque veritying capping system insures proper capping. Standard and child-safe cap capable.

Applications

Suitable for beverages, purees, baby food, nutritional & dietary supplements, liquid detergents, and more.

Specifications

Model	TT-15C-14
Machine Dimension	W 2,000 × L 2,682 × H 1,900 mm
Capacity	20 - 30 PPM
Pouch Size	W: 100-160 mm ,L: 100-250 mm
Pouch Material	Center spout stand-up pouch Center spout gusset pouch Center spout flat pouch
Liquid Filling	100 - 500 cc
Electric Power	10 kVA
Air Consumption	0.5 MPa, 300 NL/min (ANR)
Cleaning Water	0.2 MPa, 5 L/min
Accessories	Discharge conveyor Product counter Vacuum pump (0.4 kW) Heater disconnection alarm Pouch opening detection device
Options	Date printer Various inspection devices Compressor
